The input voltage: 220V/50HZ
Explosion-proof marks: Exd II C T6 Gb
Insulation grade: I
source type: LED
Power: 10-20W
Lead-in cable: ￠8 -￠12mm
Anti-corrosion grade: WF2
Scope of application
Suitable for anti-explosive gas environment zone 1, 2;
Suitable for IIA.IIB.IIC explosive gas environment;
Suitable for combustible dust environment zone 21, 22;
Applicable to the temperature classi?cation of T1~T6 environment;
Suitable for oil production, re?ning, storage, chemical, medical, textile, military and military facilities and other explosive dangerous environment;
It is compatible with all kinds of explosion-proof lamps and lanterns of our company.
Technical Parameters
| 訂貨編號 Model | 光源 Type | 功率(W) Power | 光通量(lm) Luminous | 壽命(h) life |
| XL618FB-83 | LED | 10 | 2200 | 50000 |
| XL618FB-83 | LED | 15 | 3300 | 50000 |
| XL618FB-83 | LED | 20 | 4400 | 50000 |
